Anping Chuangqian Wire Mesh Co., Ltd
| Quantità di ordine minimo: | 1 Piece/Pieces |
Color: Green
Type: Welded Mesh
Sertifikasi: Iso9001
Condition: New
Wire Diameter: 0.3mm-4mm
Mesh Hole: 1/2" 1/4" 5/8" 1" etc
Size: 1.8*3m or as Your Requirements
Tempi di consegna: 7-10 Days After Deposit
Transport Package: Waterproof Paper or According Your Request
Specification: Ce
Origin: Hebei, China (Mainland)
Codice SA: 73144100
Capacità di produzione: 1000sets/Week
Material: Galvanized Iron Wire
Hole Shape: Square
Mesh Size: 1 Inch
Trattamento della superficie: Pvc Coated
Weave Technique: Welded
Aplikasi: Construction Wire Mesh, Protecting Mesh, Cages
| Unità vendibili | : | Piece/Pieces |
The file is encrypted. Please fill in the following information to continue accessing it
| Specification of Welded Wire Mesh | ||||
| Opening | Wire Diameter |
Width 0.4-2M Length 5-50m |
electric galvanized before welded, electric galvanized after welded, hot-dipped galvanized before welded, hot-dipped galvanized after welded, PVC coated, Stainless steel wire |
|
| In inch | In metric unit | |||
| 1/4" x 1/4" | 6.4 x 6.4mm | BWG24-22 | ||
| 3/8" x 3/8" | 10.6x 10.6mm | BWG22-19 | ||
| 1/2" x 1/2" | 12.7 x 12.7mm | BWG23-16 | ||
| 5/8" x 5/8" | 16x 16mm | BWG21-18 | ||
| 3/4" x 3/4" | 19.1 x 19.1mm | BWG21-16 | ||
| 1" x 1/2" | 25.4x 12.7mm | BWG21-16 | ||
| 1-1/2" x 1-1/2" | 38 x 38mm | BWG19-14 | ||
| 1" x 2" | 25.4 x 50.8mm | BWG16-14 | ||
| 2" x 2" | 50.8 x 50.8mm | BWG15-12 | ||
| 2" x 4" | 50.8 x 101.6mm | BWG15-12 | ||
| 4" x 4" | 101.6 x 101.6mm | BWG15-12 | ||
| 4" x 6" | 101.6 x 152.4mm | BWG15-12 | ||
| 6" x 6" | 152.4 x 152.4mm | BWG15-12 | ||
| 6" x 8" | 152.4 x 203.2mm | BWG14-12 | ||
| Note: Special specifications can be made according to customers' requirements. | ||||
